By Thibault
Dambrine
But how would you really go about using
it in an application? Something built for real life work, happening every
day in your shop, like an application that would run daily as part of your
regular MIS Operations cycle.
Most of us have used FTP for the occasional
file transfer here and there. When used like that, it really feels like
a handy utility to have in a pinch. Something akin to DSPPFM in the field
of Data Transfer.
Being able to do a manual transfer here
and there is one thing, but to get some real use for this type of utility,
you would need to be able to program it and control it using table-driven
variables. How would you automate an FTP function? How would you go about
creating a process to transfer a different file every day to different
systems, the same file to different destinations or a combination of both?
In the next few paragraphs, you will get
a good idea of how you can make FTP work for you, using everyday CL, RPG
or any other high level language on the AS/400.
I will discuss configuration points to
consider, FTP theory, the FTP command set and the practical aspects of
how to implement FTP in a working program on the AS/400.
As mentioned before, FTP runs over TCP/IP.
With the popularity of the Internet, this is probably the fastest growing
communication protocol at this time. Since TCP/IP is all about communications
between systems, the best way to start this article is to discuss the configuration
aspects of TCP/IP on the AS/400.
If your AS/400 is not configured for TCP/IP
communication, this is the place to start. You will need *IOSYSCFG authority
on your own AS/400. You will also have to know some information about the
system(s) you are aiming to connect to, and the specifics on how to get
yourself connected to the destination(s) you are aiming to use (lines,
configurations etc.)
AS/400 TCP/IP supports an extensive list
of LAN and WAN connection types: Ethernet, token-ring, SDDI, FDDI, wireless
LAN, X.25 SVC, PVC and frame relay. All this to say, it is flexible, but
it requires attention to each individual situation. Documenting every situation
would probably take a whole manual, and thus, I re-direct you to the IBM
Manuals. In this case, the "TCP/IP Configuration
and Reference, Document Number SC41-5420-00".
Since this piece is about FTP, this is where I will stop for the configuration.
From this point forward, the assumption is that you are configured for
TCP/IP and your configuration is active.
How does FTP work?
To start with, here is a little bit of
theory:
FTP consists of two parts: the Client and
the Server. This Client/Server theme is common in the TCP/IP world.
The client has a user interface from which
you can enter client FTP subcommands for making requests to an FTP server.
The results of these requests are then displayed.
To transfer files between the client and
the server, two connections are established: The control connection and
the data connection. The control connection is used to request services
from the server with FTP server subcommands. The server sends replies back
to the client to indicate how the request was handled. The second connection,
known as the data connection, is used for transferring lists of files and
the actual file data.
Both the client and the server have a data
transfer function that interfaces to the resident file systems. These functions
read or write data to the local file systems and to and from the data connection.
Requests for transferring files originate from the client. The user makes these requests with the FTP client subcommands that are read by the client user interface function. The client subcommands are interpreted by the client protocol interpreter, which translates them into appropriate FTP server subcommands. The server protocol interpreter receives the subcommands from the control connection and processes it. The results of each server subcommand are transmitted back to the client in the form of an FTP server reply.
The distinction between
FTP client and FTP server is from the viewpoint of where the FTP commands
are initiated, not from the viewpoint of where the data resides. Thus,
the commands are initiated from the FTP client session, while the files
being transferred may initially reside on either system.
The File Transfer Protocol client function
allows you to send and receive copies of files to or from remote systems
across a TCP/IP network. In addition, FTP commands are provided for renaming,
appending to and deleting files. I will concentrate on the basic functionality
and usage, rather than the theory behind the protocol.
Getting
familiar with the FTP Command Set:
You can start FTP on the AS/400 by simply
typing the command "FTP" from the Command Entry Line. The system will prompt
you for the remote system name you want to connect to, your user profile
and your password. If you are not connected to any other system yet but
are curious to experiment, you can use the name "LOOPBACK" as the remote
system. This will effectively route your FTP command requests to the system
you are on currently.
A LOOPBACK connection will yield a message
that looks like "Connecting to host LOOPBACK at address 127.0.0.1 using
port XX", where XX is a port number. Note the address, 127.0.0.1. This
is an address referred to as a "Well Known Port". This means that in any
machine supporting TCP/IP, there is a 127.0.0.1 address that refers to
itself. There are several Well Known Ports and they are covered in the
TCP/IP configuration manual. Connecting to any other system will yield
a similar message with the address of the system you are logging on to.
If you are a new TCP/IP user, to see how
much you can use in this realm, simply type "HELP" on your FTP command
line once you have logged on . By "logged on", I mean logged on to FTP
rather than just "signed on" to the AS/400. This will work even if you
have a local connection to LOOPBACK. This command will show the following
menu:
| FTP Client Subcommands - Help |
| !______ ?______ ACCT___ APpend_ AScii__ Binary_ |
| CD_____ CDUp___ CLose__ DEBug__ DELete_ DIr____ |
| EBcdic_ Get____ Help___ LCd____ LOCstat LPwd___ |
| LS_____ LType__ MDelete MGet___ MKdir__ MOde___ |
| MPut___ NAmefmt NOop___ Open___ PAss___ PUt____ |
| PWd____ QUIt___ QUOte__ REInitialize______ REName_ |
| RESet__ RMDir__ SENDPort__________ SENDSite__________ |
| SIte___ STAtus_ STRuct_ SUnique SYSCmd_ SYSTem_ |
| TYpe___ User___ Verbose |
| You can abbreviate subcommands to the most unique series of characters. |
| For example, you can type AP for the APPEND subcommand. |
| In addition to these subcommands the FTP client accepts synonyms for |
| certain subcommands. |
| If the remote system is an AS/400 system, some server subcommands are |
| More... |
| F2=Extended help F3=Exit help F10=Move to top F12=Cancel |
| F13=Information Assistant F14=Print help F20=Enlarge |
The commands shown in Figure 1, starting
with "!" and ending with "Verbose", are all colored yellow. If you position
your cursor on top of any of these commands and hit ENTER, you will get
a new screen with all the syntax details of the command you have selected
and how to use it.
Here are some of the commands I use the most when dealing with FTP:
· "PING", the PING command actually runs outside of the FTP realm. It is useful, in advance of connecting, to verify if the connection between your machine and the remote system is active. To verify the connection between two systems, the PING instruction, followed by the system name you are targeting will send a simple message that will be answered by the remote machine with an echo-like response. No password is necessary in this case, the aim of PING is simply to verify if the connection is alive between two systems. If it is, you will likely have no problems using FTP.
If for example, you do a "PING LOOPBACK" from your command line, you will get the following messages:
Verifying connection to host system LOOPBACK at address 127.0.0.1.
and a communication status that will be verified 5 times:
Connection verification 1 took .001 seconds. 1 successful connection verifications.
After that, you will get the result of the test:
Round-trip (in milliseconds) min/avg/max = 0/0/1
Connection verification
statistics: 5 of 5 successful (100 %)
· "!" or "SYSCMD" lets you type in commands that will execute on the local AS/400 while you are in FTP mode. This is practical, as you can submit commands directed at your local system without having to leave the FTP mode. You could try "! PING REMOTESYSTEM" for example.
· "DIR" lets the user see libraries and their entries (files and members) or the list of directories and directory entries on the remote system. This is practical to see if a file is there to be taken or to verify if a file has arrived after a "PUT".
· "PUT" lets you send or "PUT" a file from your local AS/400 to the remote system.
· "GET" lets you retrieve or "GET" a file from the remote system to the local AS/400.
· "ASCII", "BINARY" and "EBCDIC" are ad-hoc commands that qualify your "PUT" or "GET" commands. IBM as a whole tends to work with EBCDIC. The rest of the world tends to work in ASCII. These commands help you manage the way the data is transmitted. The target file arrives in either ASCII, EBCDIC or as an exact (untranslated) replica of the original if you specify "BINARY". One note of caution, if you send files containing numeric data from your AS/400 to an ASCII-based system, ensure that all numeric fields are zoned and not packed. This will ensure the EBCDIC to ASCII table will recognize and translate all your numeric data correctly. If you try to use an ASCII to EBCDIC translation table on numeric packed fields, the results will be completely unpredictable.
· "RENAME" lets the user rename a file on the remote system. This may be practical if, after successfully GETting a file, you wish to give it a new name to the original file on the remote system.
· "QUOTE" lets the user send a command directly to the FTP server on the remote system, the command string is sent verbatim to the other system. This may be useful to trigger a process on the remote system after having transferred a file to or from it.
· "STRUCT
R" ensures records are transmitted record by record (as opposed
to a continuous stream of bytes, the default). FTP by default transmits
data as a continuous stream of bytes. If it encounters carriage return
characters, it starts a new record on the destination file, regardless
of the record length in the originating file. If for example you are transmitting
binary coded decimal data, this may cause unpredictable record lengths
in the destination file. Using "STRUCT R"
as an option will ensure the original record lengths is respected, regardless
of the presence of carriage return characters within the record.
|
|
| "LOCSITE TRIM 0"
The use of this sub-command was brought up by a Florida TUG Website reader. To illustrate its use, I will use the exact example supplied by this reader: "I am sending a 108 byte file to a UNIX box. The last 26 bytes are blank so when they get to the unix box they get lost. The customer wants it to be the full 108 bytes so I null filled the file and they complained because they want it blank and nulls are equal to a numeric. So my question is will STRUCT R keep my length of the file at 108 even though the last 26 bytes are blank. I have already been through asking to send a carriage return at 109 but they refused. Would using "STRUCT R" resolve my problem?" This user solved the problem by using a combination of two FTP subcommands: LOCSITE TRIM 0
The LOCSITE FTP subcommand specifies whether or not to transfer the trailing blanks in a database file to the remote server. The command can be used in three ways:
|
|
|
To put this all into action, here is a
practical example showing how to implement FTP in a program on the AS/400:
As explained earlier, FTP is a nifty tool
to quickly transfer files by hand between systems but its real power can
only be exploited by writing a program. The way to incorporate FTP into
your programming is not very difficult. It does however take some knowledge
of key elements.
FTP, on the AS/400, runs from the CL language
environment. Here is the methodology:
The first step is to create a source member
to contain your FTP instructions. This member can be left in a source file,
or it can be re-built at the time of running the FTP Driver Application.
This source file will contain your FTP logon and file transfer instructions.
What ever you do, it is not desirable to store the user profile and password
in an easily accessible source file. A hybrid solution consists of keeping
a source member as a template and using an RPG or any other HLL program
to replace the values that need to change. In Figure 2 example, we have
a source member in which USRPRF, PASSWORD and the two LIBRARY/FILE.MEMBER
combinations can be replaced by a program just before running the FTP command.
Another solution would consist of writing each and every record in the
source file member, in QTEMP, with an RPG (or any other HLL) program that
would concatenate every element of each line as it goes.
The example below for TEMPLATE shows a
simple scenario where we want to PUT our LOCALFILELIBRARY/LOCALFILENAME
(from our AS/400) to a REMOTEFILENAME in REMOTEFILEDIR on a remote system
The logon sequence is taken care of by the actual values replacing USRPRF
and PASSWORD.
TEMPLATE Source Member:
| 0001.00 | USRPRF PASSWORD |
| 0002.00 | PUT LOCALFILELIBRARY/LOCALFILENAME.LOCALMBR REMOTEFILEDIR/REMOTEFILENAME.REMOTEMBR |
| 0003.00 | CLOSE |
| 0004.00 | QUIT |
The second step is to create an FTP driver program
that will actually run these commands. This will be done in a CL program.
The following is a bare-bones program sample that will process the commands
in the member TEMPLATE.
Here, in four points, is the methodology for FTP implementation on OS/400 :
· Build the FTP
commands in a temporary source member
· Override the
source member containing the FTP commands to INPUT
· Override the
source member that will receive the result of the FTP commands to OUTPUT
· Use the command
"FTP RMTSYS(REMOTESYS)", where REMOTESYS is the remote system, to process
the FTP requests. FTP will automatically pick up the commands from the
source member overridden to "INPUT" and write the results in the source
member overridden to "OUTPUT". Note that REMOTESYS can also be a CL variable.
| 0001.00 BEGIN: PGM
0002.00 0003.00 /* *---------------------------------------------------------------* */ 0004.00 /* Copy The FTP input file & member in QTEMP */ 0005.00 /* *---------------------------------------------------------------* */ 0006.00 0007.00 CPYF FROMFILE(SOURCELIB/TEMPLATE) + 0008.00 TOFILE(QTEMP/SOURCEF) FROMMBR(TEMPLATE) + 0009.00 TOMBR(TEMPLATE) CRTFILE(*YES) 0010.00 0011.00 /* *---------------------------------------------------------------* */ 0012.00 /* * Call the RPG program to update the FTP input member * */ 0013.00 /* *---------------------------------------------------------------* */ 0014.00 0015.00 OVRDBF FILE(TEMPLATE) TOFILE(QTEMP/SOURCEF) + 0016.00 MBR(TEMPLATE) /* Override to the + 0017.00 member containing input commands for the + 0018.00 FTP transmission so that it can be + 0019.00 updated with the proper parameters for + 0020.00 user profile, password, file to transfer + 0021.00 to & from and direction (put or get) of + 0022.00 the transfer. */ 0023.00 0024.00 0025.00 CALL PGM(CUSTOMIZE) PARM(&PARMS) /* Update the + 0026.00 FTP input instructions member With the + 0027.00 proper UserProfile, Password, and file + 0028.00 characteristics. */ 0029.00 0030.00 0031.00 /* * CREATE FTP OUTPUT file & member in QTEMP */ 0032.00 0033.00 CRTSRCPF FILE(QTEMP/SOURCE) MBR(FTPOUTPUT) + 0034.00 TEXT('Output for FTP Result.') 0035.00 0036.00 0037.00 /* *---------------------------------------------------------------* */ 0038.00 /* * Do the actual FTP transmission using the instructions in * */ 0039.00 /* * member INPUT and putting the result of the transmission in * */ 0040.00 /* * member OUTPUT. Note that INPUT and OUTPUT are overridden. * */ 0041.00 /* *---------------------------------------------------------------* */ 0042.00 0043.00 OVRDBF FILE(INPUT) TOFILE(QTEMP/SOURCEF) + 0044.00 MBR(TEMPLATE) /* Override to the member + 0045.00 containing input commands for the FTP + 0046.00 transmission. */ 0047.00 0048.00 OVRDBF FILE(OUTPUT) TOFILE(QTEMP/FTPOUTPUT) + 0049.00 MBR(OUTPUT) /* Override to the + 0050.00 member that will contain the response + 0051.00 messages from FTP. They can be examined + 0052.00 after the transmission is finished. */ 0053.00 0054.00 FTP RMTSYS(REMOTESYS) /* This is the actual FTP Command Request */ 0055.00 0056.00 CPYF FROMFILE(OUTPUT) TOFILE(*PRINT) /* Print the + 0057.00 results of this transmission. */ 0058.00 0059.00 /* *---------------------------------------------------------------* */ 0060.00 /* * Call the RPG program to evaluate the result of the output file* */ 0061.00 /* *---------------------------------------------------------------* */ 0062.00 0063.00 CALL PGM(EVALUATE) /* On a + 0064.00 "put", look at the result member for + 0065.00 succesful FTP completion. On a "get", + 0066.00 look at both the FTP completion messages + 0067.00 and compare the number of records in the + 0068.00 file received. */ 0069.00 0070.00 DLTOVR FILE(INPUT OUTPUT) 0071.00 0072.00 ENDPGM |
Notes:
· As mentioned earlier, how you build the INPUT source member can be done in many ways. In this case, I have used a template that a program then changes. You can build it however you want, as long as the FTP syntax is correct. In this case, the INPUT member is in QTEMP. This way, when the job ends the customized file and member containing the user profile and password to the remote system disappear with the end of the job. Others may choose to create all the records at the last minute, not using a template.
· This INPUT member example shows a PUT action. You can do a GET, a RENAME or any other legal FTP instruction and it will work the same way, provided the syntax is good.
· What you want to do with the OUTPUT member is your choice. You don't have to do anything with it if you don't want to. I have found it convenient to read it in a program and analyze the FTP responses to figure out if the transfer was successful. As it turns out, you will notice in an automated process, knowing if you are successful in your transfer is just as important as transferring the data itself. The technique to figure out if the transfer went well is to read the OUTPUT member and look for certain FTP messages.
· If you design a prototype application, you can run it with the address LOOPBACK. You can send a file for example from one library to another on the same system.
· Note: When communicating with a UNIX operating system based system, the AS/400 file format notation "LIBRARY/FILE(MEMBER)" is translated as "DIRECTORY/FILE.MEMBER", where the member name becomes the extension. This relationship goes both ways, i.e. if you GET a file from a UNIX based remote system, the extension of that file will be used as the member name.
· Note: Most times, having just
the User Profile and the Password is enough. However, some operating systems
and their FTP servers are more picky. You might have to provide explicit
logon commands, as in "USER USERNAME" and then "PASSWORD USERPASSWORD".
Another consideration, when it comes to communicating with systems other
than AS/400 is lower-case passwords. If the system you are communicating
with has a case-sensitive password, you could get frustrating experiences
of not getting in even if you have the correct password (however in incorrect
case, e.g. "Password" instead of "password"). The error message will not
tell you anything too explicit.
Here are several examples of what you could
get as an FTP OUTPUT.
This is an example of what you could get as an FTP
output, note that the password used will not be transcribed into that OUTPUTmember
by FTP, only the User Profile is showing. In this case, the transmission
was successful. This transmission was done from an AS/400 system to an
IBM MVS system. Here, the success message is 250, "File transfer completed
successfully". An easy way to have a physical trace of the transfer is
to do a simple CPYF to *PRINT of this member after the transfer has occurred.
Sample OUTPUT result for a successful FTP
communication to MVS System
| *************** Beginning of data *****************************************
0001.00 Output redirected to a file. 0002.00 Input read from specified override file. 0003.00 Connecting to host 999.999.99.9 using port 99. 0004.00 220-FTP IBM MVS V3R2 at XXXX, 18:33:22 on 1998/08/01 0005.00 220 Connection will close if idle more than 5 minutes. 0006.00 MVS is the operating system of this server. 0007.00 Enter login ID (TESTUSER): 0008.00 331 Send Password Please. 0009.00 230 TESTUSER logged on. Working Directory is "TESTUSER.". 0010.00 Enter an FTP subcommand. 0011.00 > GET DATA.SET.NAME LOCALFILEDIR/LOCALFILENAME 0012.00 200 Port request OK. 0013.00 125 Sending data set DATA.SET.NAME 0014.00 250 Transfer completed successfully. 0015.00 2530952 bytes transferred in 63.651 seconds. Transfer rate 39.763 KB/sec. 0016.00 Enter an FTP subcommand. 0017.00 > CLOSE 0018.00 221 QUIT subcommand received. Goodbye. 0019.00 Enter an FTP subcommand. 0020.00 > QUIT |
Note:The
text in the 250 code and other FTP return codes can vary depending on the
system you are communicating with. It may say "Transfer completed successfully"
in the case of an AS/400 to MVS system or "File transfer completed successfully"
in the case of a transfer from AS/400 to AS/400. Also, in the case of a
loopback to AS/400, the 250 message may appear twice. Once saying "Now
using naming format "0" and once saying "File transfer completed successfully".
These are subtle differences, but basically you should check the message
number rather than the text with your error checking program.
When you write your error checking program it is
a good idea to experiment first and check for the success messages that
you can expect from what ever combination of systems you are transferring
from and to.
Here is a sample of a transfer from an
AS/400 to my own PC, using the Reflections 5250 emulator & FTP server
product as a remote system. Note the differences in how the output can
vary when communicating with one system or the other.
Sample OUTPUT result for a successful FTP
communication to my own PC, using Reflections 5250 emulator and FTP server.
| *************** Beginning of data *****************************************
0001.00 Output redirected to a file. 0002.00 Input read from specified override file. 0003.00 Connecting to host 999.999.99.9 using port 99. 0004.00 220 Reflection FTP Server Version 6.20 Thursday 08/20/1998 15:07:44 0005.00 Reflection FTP Server. 0006.00 Enter login ID (TESTUSER): 0007.00 Guest login OK 0008.00 Welcome Message from Reflections PC Server 0009.00 230 TESTUSER logged in. 0010.00 Enter an FTP subcommand. 0011.00 > GET C:\DATA.TXT LOCALFILEDIR/LOCALFILENAME 0012.00 200 Port request successful. 0013.00 150 Transfer started from file "C:\DATA.TXT" (46 bytes) 0014.00 226 Transfer complete (0.00 KB/sec) 0015.00 46 bytes transferred in 13.532 seconds. Transfer rate 0.03 KB/sec. 0016.00 Enter an FTP subcommand. 0017.00 > CLOSE 0018.00 221 Goodbye. 0019.00 Enter an FTP subcommand. 0020.00 > QUIT |
Note that in this case,
we
did not receive the 250 message at all. Rather, we got a 226 message,
its equivalent. This is another illustration of how different systems can
respond. Again, a reminder to test and try the communication manually to
see what you get message-wise when you transmit data between any two systems.
Of course, you can code an FTP result checking application that can check
for 250 and 226 return codes. This is probably the best thing to do. The
Microsoft FTP Service (no example provided here but I did try it) also
yields a 226 message rather than a 250.
Here is an example of a failed transmission. The
easiest way to know that things went wrong is that you will not find in
this OUTPUT member any successful completion message. Failing to find such
a message, your program can notify you for failure.
Sample OUTPUT result for a failed FTP communication
| *************** Beginning of data *****************************************
0001.00 Output redirected to a file. 0002.00 Input read from specified override file. 0003.00 Connecting to host ABCZZZ at address 999.999.99.9 using port 99. 0004.00 220-QTCP at AAABBBCCC. 0005.00 220 Connection will close if idle more than 10 minutes. 0006.00 215 OS/400 is the remote operating system. The TCP/IP version is "V3R1M0". 0007.00 Enter login ID (TESTUSER): 0008.00 331 Enter password. 0009.00 230 TESTUSER logged on. 0010.00 250 Now using naming format "0". 0011.00 257 "TESTUSER" is current library. 0012.00 Enter an FTP subcommand. 0013.00 > PUT LOCALFILELIBRARY/LOCALFILENAME REMOTEFILEDIR/REMOTEFILENAME 0015.00 501 Specified object name too long, limit is 10 characters: REMOTEFILENAME. 0016.00 Enter an FTP subcommand. 0017.00 > CLOSE 0018.00 221 QUIT subcommand received. 0019.00 Enter an FTP subcommand. 0020.00 > QUIT |
As you can see, the results of the FTP commands are
preceded by a reply code. The reply code list can be found in the TCP/IP
Configuration and Reference manual, but in case you don't have it, here
is a copy:
FTP Reply Codes
| Code | Description |
| 110 | Restart marker reply |
| 120 | Service ready in nnn minutes |
| 125 | Data connection already open; transfer starting |
| 150 | File starting OK; about to open data connection |
| 200 | Command OK |
| 202 | Command not implemented; not used on this system |
| 211 | System status, or system help reply |
| 212 | Directory status |
| 213 | File status |
| 214 | Help message |
| 220 | Service ready for new user |
| 226 | Closing data connection; requested file action successful |
| 230 | User logged in |
| 250 | Requested file action okay, completed |
| 257 | Path name created |
| 331 | Password required |
| 332 | Account required |
| 425 | Cannot open data connection |
| 426 | Connection closed; transfer ended abnormally |
| 450 | Requested file action not taken; file busy |
| 451 | Requested action ended abnormally; local error in processing |
| 452 | Requested action not taken; insufficient storage in system space |
| 500 | Syntax error; command unrecognized |
| 501 | Syntax error in parameters or arguments |
| 502 | Command not implemented |
| 503 | Bad sequence of commands |
| 504 | Command not implemented for that parameter |
| 530 | Logon attempt rejected |
| 532 | Need account for storing files |
| 550 | Requested action not taken; file not found or no access |
| 551 | Requested action ended abnormally; page type unknown |
| 552 | Requested file action ended abnormally; exceeded storage allocation |
| 553 | Requested action not taken; file name not allowed |
The code examples supplied above are basic in nature.
They do not include the RPG programs necessary to plug in user profiles,
passwords and library/file names necessary to do actual transfers. They
also do not include any example programs to read the OUTPUT result member
and verify success or failure of a transfer. These programs can be coded
in several languages and hopefully, there is enough information here to
start a programmer on the path of FTP automation for your AS/400 applications.
Another point to take note of is that all fatal errors have error numbers
greater or equal to 331. This can be used as a method to check for failure
rather than success (i.e. looking for 250 or 226 codes).
In Conclusion
More and more, rather than using a tape or any other
physical media transfer, the IS user community is demanding file transfer
solutions that are seamless and do not require physical intervention. In
this respect, FTP is a simple, cost-effective solution. It is easy to implement
and it comes built-in with OS/400.
The business of transferring data between different
types of machines is growing in every direction. Competition for FTP's
simple abilities abound. IBM's MQ series product, for example, promises
guaranteed queued data delivery to virtually any type of remote system.
Products like NDM, INFOPUMP and BEA's TUXEDO to name only a few, propose
products that will transfer data seamlessly between systems with recovery
features that help IS managers sleep more comfortably (at a cost!).
In this perspective, FTP is a simple product. It
has some advantages, being bundled with OS/400 and is relatively easy to
program & operate (read cheap). It does however have short-comings
on the recovery side. This is an exposure to consider if you deal with
sensitive data. If you decide to use FTP on a regular basis, especially
in production mode, verification of the success of your transfer and recovery
procedures will be an issue to look into. On the bright side, physical
communication links these days are very reliable. My personal experience
with FTP is that most times, a communication failure will usually come
from a system problem rather than a "wire" link problem. Still, evaluating
the best tool for transferring data between systems remains a case-by-case
analysis.
This article has been published previously in the Toronto
User Group for Midrange Systems Newsletter (www.tug.ca)
| Letters from Readers |
| Hany, from Saudi Arabia wrote:
I am trying to ftp file from AS400 machine to RS6000 one. The text is
mixed Arabic and English.
Response:
Hany found himself the way to do this. He resolved the problem in the following steps: 1) Retrieve the source of the QASCII translation table, using RTVTBLSRC. This takes the contents of the translation table and dumps them into a regular source file. 2) Modify the newly retrieved translation table, using values that would meet the specific requirements of the transfer. Note: this table contains only the translation, for example, in QASCII, EBCDIC Hex 04 translates to ASCII Hex 9C. In the translation table, only 9C will show. An easy way to see this type of table is to use the Work with Tables (WRKTBL) command. Pick the table you want to see and put a 5 in front of it. This will display the values inside the table. I have also suggested to Hany to look at the following website: ftp://ftp.unicode.org/Public/UNIDATA/ which contains a number of hex tables for foreign languages. 3) Re-Create the translation table using CRTTBL. Note that the table type is *CVT. Note, it is a good idea not to override a standard IBM table, like QASCII or QEBCDIC. Rather, create your own version of a new table, say "XASCII" or "XEBCDIC" for example. 4) When starting an FTP session, automated or manual, you will use the FTP command. This command is promptable. If you hit F4, you will only get the remote system parameter, but if you hit F10 after that, you will get a new set of parameters, amongst which there is the name of the incoming and outgoing ASCII/EBCDIC tables to use. At this point, you can enter your own customized version of the translation table, as in "XASCII" or "XEBCDIC" for example. 5) Test your new setup with FTP
transmissions of data sets that will allow you to reliably verify the desired
results.
|
| Jeff, from Chicago, wrote:
I'm wondering if you could point me in the right direction on a problem I'm currently having with the AS/400 FTP client? I am using the WAR FTP Daemon on my PC. Using the AS/400 FTP client, I can GET files from my PC to the 400, but when I try to PUT a file, nothing happens. An empty shell of the file is created on the PC, but no data transfer takes place. The WAR FTP Daemon responds with: 227 Entering Passive Mode (nn,n,n,nnn,n,nn)
This is all that happens - no data gets transferred. Ultimately, my
goal is to automate PUTting Domino/Notes files from the AS/400 to my Network.
Can you help me?
Response: As far as WAR FTP, did you study the possible settings in the manual (assumed) supplied with the software? Perhaps the answer is simpler than you would think. I had very reliable and consistent success with an FTP software package for Windows called WS_FTP Server, by IPswitch. IPswitch has a website at http://www.ipswitch.com. You can order the product and download the manuals on-line. Jeff wrote: Thanks for your help -- I found my problem. It was with the PASV
subcommand. I needed to turn it off. Everything seems to be
working now.
|
| Send your Letter to Thibault at dambrine@tylogix.com. Maybe it will be published in a future udate. |
Thibault Dambrine is a Computer Consultant, based in Calgary, Alberta (Canada). He can be reached at (403) 263-6556 or via e-mail at dambrine@tylogix.com.
